Description

Nuance® Dragon® Medical Practice Edition 4 with Dragon Veterinary and Philips SMP4010

Let Dragon Veterinary work for you

All of the Advantages

IMPROVES AND COMPLIMENTS THE LEADING VETERINARY SOFTWARE THAT YOU USE EVERYDAY

REDUCE OR ELIMINATE THE NEED TO TYPE

SPEED UP YOUR WORKFLOW AND GIVE YOU MORE TIME IN YOUR DAY

SPEND LESS TIME AT THE COMPUTER AND MORE TIME WITH YOUR PATIENT

Dragon Veterinary software is built by our team of board certified radiologists who have extensive experience with all modalities of veterinary teleradiology says Brian A. Poteet, DVM, Dip. ACVR

Gain more time in your day by speech enabling your practice using Dragon Medical Practice Edition 4 with Dragon Veterinary into your Practice Management Software of choice.  Most people can speak 150 words per minute.  How many words can you type per minute?  How many errors?  Most veterinarian's are completing a minimum of 2-3 times more reports per day dictating rather than typing or writing.   Dragon Veterinary will provide you with the best solution to go with a quick paperless environment and run your practice more efficiently.

Most importantly, it allows you to do what you do best as a veterinarian and that's treating your very special patients with special care.

Partial list of Practice Management Software Dragon Veterinary is compatible with:

• AviMark
• Cornerstone
• DVmax
• Impromed Infinity
• Intravet
• Animal Intelligence
• e-Vet Practice
• Vet Office Suite
• VIA Veterinary Information Systems

SMP4000

Studio-quality microphone for best-in-class speech recognition results

The SpeechMike Premium Air comes with a studio-quality microphone and a built-in tripple layer noise reduction filter for clearest recordings and most accurate speech recognition results.

Decoupled free-floating microphone for precise recordings without background noise

The free-floating microphone is decoupled from the device’s housing, which guarantees that almost no background, touch, click, air or structure-borne noise is recorded.

Integrated motion sensor mutes microphone when not in use

Being on the cutting edge of technology, the SpeechMike Premium Air comes with an integrated motion sensor, meaning it can be controlled by the movement of your hand. It detects when it’s put on the table, mutes the microphone, and once it is being picked up again it unmutes the microphone. In addition to that, custom events can be programmed, e.g., to pause and to continue the recording.

Patented 100% lossless speech technology for smooth wireless voice recording

Uncompressed wireless recording enables free movement and pacing whilst working. You can easily move up to 5 meters or 16 feet away from your workstation and your recordings are safely transmitted to your computer in highest quality, without any interruptions. The cutting edge technology ensures every word is captured from the moment you press record.

Superior docking station for high-speed wireless charging and smart pairing

The stable and innovative docking station provides wireless high-speed charging and easy pairing between your device and the docking station. Users can be flexible and work with various docking stations in different places. With an optional foot control connected, the docking station enables hands-free recording.

Freely configurable buttons and modes for a personalized device

You can freely configure the buttons on your device or use the pre-installed Secured Dragon Mode. This mode pre-configures the buttons, optimizing them for use with Dragon speech recognition software. It requires no additional driver installation, making set up easy, even in virtual environments.

Wear-free slide switch and push buttons for comfortable operation

The SpeechMike Premium Air comes with slide-switch or push-button operation. The slide switch is ergonomically shaped with a softly ribbed surface for smooth tactile feedback and comfortable and intuitive utilization. In addition, our engineers implemented a millionfold proven contactless slider detection, making it completely wear-free for an extra-long lifetime.

Antimicrobial housing and buttons for durable hygienic working

The housing of the SpeechMike Premium Air is made of antimicrobial synthetics that work against a wide range of different microorganisms such as bacteria, viruses, fungi or algae. The polished, high quality pearl metal surface also makes the device non-sensitive to touch noises and fingerprints.

Superior touch sensor for integrated mouse function

The device comes with a dust and dirt resistant touch sensor for superior quality. This allows the user to easily control and navigate within applications while recording, without having to switch between the mouse and microphone.

Hands-free recording for comfortable working

An optional foot control can be connected directly to the docking station and used for comfortable hands-free recording control.

Smart, backwards compatible firmware for extra flexibility

Customers can upgrade from their previous SpeechMike model without installing additional software. For integrators, this means no changes need to be implemented and the existing SDK can be used. The SpeechMike Premium Air is compatible with Mac and Windows operating systems, as well as virtual environments such as Citrix, VM Ware and Hyper-V. It can be configured using SpeechControl, the convenient Philips hardware management tool.

Specs

Recommended System Requirements:

• CPU: 2.4 GHz Intel Dual Core or equivalent AMD processor.
• Processor Cache: 2 MB
• Free hard disk space: 4 GB
• RAM: 4 GB for Windows 7, 8 and 2008 64-bit/2012
• Microsoft Internet Explorer 11 or higher, or the current version of Chrome
• Creative® Labs Sound Blaster® 16 or equivalent sound card supporting 16-bit recording
• DVD-ROM drive required for installation. Flash drives can be procured for a nominal charge. Some resellers offer a downloadable version

Supported Operating Systems:

• Microsoft Windows 8, 32-bit and 64-bit
• Microsoft Windows 7, 32-bit and 64-bit
• Windows Server 2008, R2 and 2012 R2

Applications:

• DragonPad
• WordPad
• NotePad
• Microsoft® Word 2010, 2013, 2016
• Microsoft® Outlook® 2010, 2013, 2016
• Microsoft® Excel® 2010, 2013, 2016
• Internet Explorer 11

A web connection is required for activation during installation. The software checks your system for minimum requirements; if they are not met, Dragon Medical Practice Edition will not be installed.

Philips SMP4010 Specifications:

Connectivity

Wireless technology: 2.4 GHz ISM Band

Modulation: 8-FSK

Maximum range: up to 5 m / 16 ft (in clear view)

Audio recording

Microphone type: electret condenser microphone

Microphone capsule: 10 mm

Characteristic: uni-directional

Frequency response: 200 – 12 000 Hz

Sensitivity: -37 dBV Signal-to-noise ratio: > 70 dBA

Sound

Speaker type: built-in round, dynamic speaker

Speaker diameter: 30 mm

Acoustic frequency response: 300 – 7500 Hz

Speaker output power: > 200 mW

Power

Battery type: Li-polymer

Rechargeable: wireless via docking station or micro USB

Power supply: via docking station

Battery lifetime: up to 24 hours of recording

Standby time: > 100 hours

Charging time (full charge): 3 h (wireless)

Dimensions

Product dimensions (W × D × H): 45 × 175 × 32 mm / 1.8 × 6.9 × 1.25 in

Weight: 120 g/4.2 oz

Docking station

Product dimensions (W × D × H): 82 × 85 × 60 mm / 3.2 × 3.3 × 2.4 in

Weight: 276 g/9.7 oz

USB: for foot control

Micro USB: data connection

Kensington Lock
